Description
Baja Designs 6 XL Linkable LED Light Bar with 6 amber lens kits, 6 rock guards, a wiring harness w/switch, and pre-load center support kit. Features 6 XL Sport Lights (4.43 inch diameter). Total output: 18,900 raw lumens.
Experience full adjustment and total performance with the Baja Designs XL Linkable LED light bar kit, engineered for enthusiasts seeking to take charge with a lighting package that is completely customizable. Built around our popular XL Sport shallow moto housing, each light offers up 3,162 raw lumens each from our next generation LEDs, the XL Linkable can be built with 3 up to 8 forward projecting lights that provide a smooth blend due to the use of our wide cornering, driving combo and spot lenses illuminating zones 1, 2, 3 and 4 simultaneously. The unique feature of our XL Linkable system provides 45 degrees of vertical pitch adjustment within each light or the entire unit. Completely independent horizontal adjustment per light allows for straight or arc configurations to perfectly match the lines of your vehicle’s bumper or roofline. The wiring comes fully crimped and trimmed, allowing for easy installation and the ability to add links down the road, and black rock guards are included to protect the lights when not in use. If you’re looking to have a lighting system that performs as well as it looks, this is the auxiliary light kit for you!
The 7 XL Linkable setup includes the following:
(1) XL Linkable, 6 XL Clear
(2) XL Amber Wide Cornering Lens Kits
(4) XL Amber Driving/Combo Lens Kits
(6) XL Black Rock Guards
(1) On/Off Wiring Harness
(1) Pre-load kit (bracket that takes load off the center of the light to prevent vibration).
Features:
45 degrees of vertical pitch adjustment within each light or the entire unit.
Independent horizontal adjustment per light allows for straight or arc configurations.
Pre-Load kit included.
Black rock guards included.
Harness included (640115).
Limited Lifetime Warranty – Complete Purchase Protection
uService – Replaceable Lenses And Optics
ClearView – All The Light, Right Where You Need It
MoistureBlock – Waterproof, Rain Proof, Submersible
CopperDrive – Safely Driving LEDs at 100 Percent
5000K Daylight – Less Driver Fatigue, Natural Color
Specifications:
Dimensions
Depth (in.) 2.8
Height (in.) 4.43
Length (in.) 39.16
Specifications
Amperage Rating (A) 12
Average Rated Life (hr.) 49,930
Beam Pattern Multi-Pattern
Bezel Material Billet Machined Aluminum
Brightness (Lumens) 18,900
Description 6XL Sport; Multi-Pattern; Clear
Housing Color Black
Housing Material Hard Anodized and Powder Coated Cast Aluminum
Lens Color Clear
Lens Material Hardcoated Polycarbonate
Light Quantity 6
Lighting Modes Beam
Lighting Quantity 24
Lighting Technology LED
Lighting Type Forward Projecting
Mounting Hardware Description Pre-Load Kit; Links; Rock Guards
Mounting Hardware Included Yes
Mounting Hardware Material Stainless Steel
Overvoltage Protection Built-In
Product Type XL Linkable LED Light Bar
Universal or Specific Universal
Wattage (W) 156
Wiring Harness Included Yes
Standards & Compliance
Standards/Compliance (Durability) Exceeds MIL-STD810G (Mil-Spec Testing)
Standards/Compliance (Impact Resistance) IK10 Compliant (Mechanical Impact Testing)
Standards/Compliance (Water Resistance) IP69K (Waterproof up to 9ft & Pressure Washable)
