Description
The Squadron Sport angled mount LED auxiliary light produces an impressive 3,162 lumens at 30 watts making it ideal for near field, side/backup, or scene lighting applications. Paired with our work/scene lens, this light is ideal for mounting on the side of a vehicle or trailer and gives a usable work light for camp, pit, or any work area that needs illumination. The 25-degree angled housing is perfect for the side of trailers or any application where you need an angled mount solution for auxiliary lighting. The angled flush mount allows you to easily mount to a flat surface by only drilling three small holes. The light comes with all the necessary hardware to make installation straightforward. Backed by our 30-Day Satisfaction Guarantee and Limited Lifetime Warranty for the ultimate in purchase protection. NOTE: This light does not come with a wiring harness. The applicable wiring harness for this light is 640117 (Squadron 2-Light Max Wiring Harness 150w). USPTO Reg No. 5,766,659
uService – Replaceable Lenses And Optics
ClearView – All The Light, Right Where You Need It
MoistureBlock – Waterproof, Rain Proof, Submersible
CopperDrive – Only LED Driven At 100 Percent
5000K Daylight – Less Driver Fatigue, Natural Color
Detailed Specs
SKU: 552006
Dimensions
Depth (in.) 2.770
Height (in.) 3.070
Length (in.) 3.070
Weight (lbs.) 0.750
Specifications
Amperage Rating (A) 2.200
Average Rated Life (hr.) 49,930
Beam Pattern Work/Scene
Bezel Material Billet Machined Aluminum
Brightness (Lumens) 3162
Description Angle Mount; Work/Scene; Clear
Housing Color Black
Housing Material Powder Coated Cast Aluminum
Lens Color Clear
Lens Material Hardcoated Polycarbonate
Light Quantity 1
Lighting Modes Beam
Lighting Quantity 4
Lighting Technology LED
Lighting Type Forward Projecting
Mounting Hardware Included Yes
Mounting Hardware Material Stainless Steel
Overvoltage Protection Built-In
Product Type Squadron Sport Angle Mount LED Light Pod
Wattage (W) 30.360
Wiring Harness Included No
Standards & Compliance
Standards/Compliance (Durability) Exceeds MIL-STD810G (Mil-Spec Testing)
Standards/Compliance (Impact Resistance) IK10 Compliant (Mechanical Impact Testing)
Standards/Compliance (Water Resistance) IP69K (Waterproof up to 9ft & Pressure Washable)
