Description
The FOX® 983-02-054 Performance Series 2.0 IFP Coilover Shock is a front-position, aluminum-bodied coilover with 4.19in of travel, built for 2005-2021 Nissan Frontier, 2005-2012 Nissan Pathfinder, and 2005-2015 Nissan Xterra applications running 0in-2in of lift.
IMPORTANT: Fitment is front position only and covers a 0in-2in lift range. Year coverage varies by model: 2005-2021 Nissan Frontier, 2005-2012 Nissan Pathfinder, and 2005-2015 Nissan Xterra. This listing is for one (1) front coilover shock, sold individually. A second unit is required to complete the front axle, and the rear shock is sold separately.
This bolt-on Performance Series Coil-Over IFP shock is designed as a direct replacement that requires no modification to install. It is engineered to level the truck front-to-rear and is available for both stock-height and lifted applications that re-use the stock shock mounting.
The shock body is a 2.0in impact-extruded and CNC-machined 6061-T6 aluminum one-piece design with a clear-anodized finish that increases cooling capacity and resists rust over time. Internally, an Internal Floating Piston (IFP) monotube design separates the shock oil from a high-pressure, nitrogen-charged gas chamber, eliminating oil aeration so the factory-tuned, application-specific valving performs consistently. A locking, threaded spring preload ring retains a racing-spec coil spring selected to deliver the correct spring rate and allows ride height and preload adjustment. The vehicle-specific upper mount uses a composite bushing to isolate noise and vibration.
Componentry is black-anodized, CNC-machined 6061-T6 billet aluminum, and the shaft is 5/8in hard chrome-plated, heat-treated alloy steel. Sealing is handled by a redundant pack system (main seal, wiper seal, scraper seal) riding on large-diameter, heavy-duty spherical bearings for long service life. FOX backs this shock with a Limited Lifetime Warranty.
- Front-position coilover shock: 2005-2021 Nissan Frontier, 2005-2012 Nissan Pathfinder, 2005-2015 Nissan Xterra, 0in-2in lift range
- 2.0in impact-extruded, CNC-machined 6061-T6 aluminum body with clear-anodized finish
- Internal Floating Piston (IFP) monotube design separates oil from nitrogen-charged gas chamber
- Application-specific, factory-tuned valving and race-developed high-flow piston
- Locking, threaded spring preload ring for ride height and preload adjustment
- 5/8in hard chrome-plated, heat-treated alloy steel shaft
- Redundant sealing pack (main, wiper, and scraper seals) on large-diameter spherical bearings
- Vehicle-specific upper mount with composite bushing for noise and vibration isolation
- Backed by FOX Limited Lifetime Warranty
- Sold individually
| Part Number | 983-02-054 |
| Brand | FOX® |
| Series | Performance Series 2.0 |
| Type | IFP Coilover Shock |
| Position | Front |
| Lift Height | 0in-2in |
| Fitment – Frontier | 2005-2021 Nissan Frontier |
| Fitment – Pathfinder | 2005-2012 Nissan Pathfinder |
| Fitment – Xterra | 2005-2015 Nissan Xterra |
| Travel | 4.19in |
| Extended Length | 15.69in |
| Compressed Length | 11.5in |
| Body | 2.0in impact-extruded and CNC-machined 6061-T6 aluminum, one-piece, clear-anodized |
| Components | Black-anodized, CNC-machined 6061-T6 billet aluminum |
| Shaft | 5/8in hard chrome-plated, heat-treated alloy steel |
| Piston | Race-developed high-flow piston design |
| Valving | Application-specific valving |
| Seals | Redundant sealing pack: main seal, wiper seal, scraper seal |
| Bearings | Large diameter, heavy-duty spherical |
| Top Mount | TM |
| Bottom Mount | Eyelet |
| Warranty | Limited Lifetime Warranty |
| What’s Included | (1) FOX® Performance Series 2.0 IFP Coilover Shock, Front |
| Quantity | Sold individually |
This coilover shock fits the front axle only, in a 2.0in aluminum-bodied IFP configuration for a 0in-2in lift range. Coverage spans 2005-2021 Nissan Frontier, 2005-2012 Nissan Pathfinder, and 2005-2015 Nissan Xterra. This is not the rear shock and is not sold as a pair; confirm your model year against the ranges above before ordering, and order two units to complete a front axle set.
