Description
Perrin PSP-OIL-111 Oil Cooler Full Kit for 2015-2021 Subaru WRX. Reduce engine oil temp, extend engine life, and keep your engine’s output consistent. Estimated install time: 2 hours.
Included in box:
(1) PERRIN Oil Cooler Core
(1) PERRIN Oil Filter Spacer
(1) Oil Line Assembly, Short
(1) Oil Line Assembly, Long
(2) PERRIN Mounting Brackets
All Hardware for Installation
Warranty & Instructions
Reduce engine oil temperatures, extend engine life, and keep your horsepower consistent with a PERRIN Oil Cooler.
Specs:
- Oil Cooler Core Dimensions 9.5″ x 4.75″ x 2.2″
- Core Delta PSI 3.0/3.5 PSI
- Core BTU/hr Range 22,000-29,000
- Additional Oil Required 1 quart
- Mounting Brackets 304 Stainless Steel
- Filter Spacer 6061 T6 Aluminum
- Oil Cooler Thermostat 85°C Activation Temp
- Hose Size -10
- Hose Construction AQP Elastomer Tube, Textile Braid Reinforcement, AQP Elastomer Cover
Manufacturer’s Description:
In racing conditions engine oil temperature skyrockets. This causes decreased engine performance and reduces the oil’s ability to properly lubricate. A well-designed engine oil cooling system like the PERRIN Oil Cooler Kit will help keep temperatures within the desired temperature range, thus maintaining performance and prolonging engine life. Most setups can see a drop of approximately 15°-20°F at 7000 RPM.
BAR AND PLATE CORE
Each PERRIN oil cooler uses a high-efficiency PERRIN bar and plate-style oil cooler core. This core design maximizes heat dissipation without restricting oil flow to ensure your engine is fed with full oil pressure. This bar and plate design is much stronger and withstands damage from normal road debris more efficiently than tube and fin type cores. The mounting holes and hose connection points are also more durable.
INTEGRATED THERMOSTAT
The PERRIN Filter Adapter features an integrated 85°C (185°F) thermostat. This means your oil will reach the optimum operating temperature of 85°C within the engine before it is released to the oil cooler.
OIL FILTER
In addition to a new OEM oil filter from Subaru, we include a PERRIN Oil Spacer to allow for easy installation of the thermostat-filter assembly.
MOUNTING BRACKETS
The PERRIN Oil Cooler comes with custom brackets that allow the oil cooler to mount easily to the front of your vehicle. Made with 304 Stainless Steel to ensure the brackets last the life of the car.
PREASSEMBLED HOSES
Full PERRIN Oil Cooler Kits feature lightweight Aeroquip brand -10 hose that are rated for 250psi and 300°F continuous temperature. Each hose comes pre-assembled and wrapped with our Industrial grade Pyrojacket that can withstand continuous exposure to 500° F (260°C) and up to 2000°F (1090°C) for 15-20 minutes.
TUNER KITS
PERRIN Oil Cooler Tuner Kits are perfect for custom race applications and/or show car setups where you want to create your own custom hoses and fittings. A PERRIN Oil Cooler Tuner Kit will supply the core and brackets, you supply the rest.
