Description
Bilstein B8 5100 (Steering Damper) is designed as an upgrade to factory steering dampers on trucks and SUVs. Utilizing our proven design, these steering dampers are able to dampen minute movements in the steering and reduce steering vibrations that naturally occur, especially in older vehicles. These steering dampers are zinc coated for resistance to harsh elements and match to all B8 5100 series products. B8 5100 (Steering Damper) will offer a significant improvement in steering, handling and comfort.
Specs for Steering Damper:
Collapsed Length (in): 16.93
Extended Length (in): 26.50
Collapsed Length (mm): 430.0
Extended Length (mm): 673.0
Stroke/travel Length (in): 9.57
Lower Mount Type: Cantilever
Upper Mount Type: Eye 12mm
Internal Design: Monotube
Finish: Zinc Plated
Reservoir: No
Body Design: 46mm ID Smooth Body (Non-Coilover)
Body Diameter (od): 2.0 in.
Boot Included: Black Bellows
Replacement Mounting Kit: B4-KT1-Z279A00
Spring Seat Included: No
Shaft Diameter: 11mm
