Description
FOX® 983-02-142 2.0 ATS (Adjustable Through Shaft) Factory Race Series steering stabilizer with a 1-1/2 inch tie rod clamp fits 2007-2018 Jeep Wrangler JK models.
IMPORTANT: This stabilizer is built for a 1-1/2 inch tie rod clamp diameter. FOX® also offers this ATS stabilizer sized for 1-5/8 inch tie rods (part number 983-02-146) and for stock and 1-3/8 inch tie rods (part number 983-02-145) – confirm your tie rod diameter before ordering, as none of these three clamp sizes are interchangeable.
Conventional steering stabilizers create a push-pull force as the shaft occupies more volume in one direction than the other, displacing oil and unevenly loading the system. the FOX® Factory Race Series 2.0 Stabilizer ATS eliminates this by using an Adjustable Through Shaft (ATS) architecture, which removes shaft fluid displacement throughout the stabilizer’s entire travel in both directions.
An external piggyback reservoir adds fluid capacity and uses an Internal Floating Piston (IFP) to separate shock oil from the nitrogen gas charge, preventing cavitation under hard use. An external adjuster provides 24 clicks of compression adjustment, letting you dial in steering feedback damping to your driving style and setup without removing the stabilizer from the vehicle.
The 2.0-inch metal-impacted, clear-anodized 6061-T6 aluminum body resists corrosion, while a 5/8-inch hard chrome-plated, heat-treated alloy steel shaft and a redundant sealing pack (main seal, wiper seal, scraper seal) keep the unit protected in harsh off-road conditions. Application-specific mounting hardware is included, and FOX® backs the unit with the FOX® Limited Lifetime Warranty.
- Fits 2007-2018 Jeep Wrangler JK, 1-1/2in tie rod clamp
- ATS (Adjustable Through Shaft) architecture eliminates shaft fluid displacement in both directions
- 24-click external compression adjuster for tunable steering feedback damping
- External piggyback reservoir with IFP separates oil from nitrogen charge to prevent cavitation
- 2.0″ clear-anodized 6061-T6 aluminum body
- 5/8″ hard chrome-plated heat-treated alloy steel shaft
- Includes application-specific mounting hardware
- Backed by the FOX® Limited Lifetime Warranty
- Sold individually
| Part Number | 983-02-142 |
| Series | Factory Race |
| Architecture | ATS (Adjustable Through Shaft) |
| Adjuster | 24-click external compression adjuster |
| Travel | 8.12 in |
| Body | 2.0″ clear-anodized 6061-T6 aluminum |
| Shaft | 5/8″ hard chrome plated heat-treated alloy steel |
| Extended Length | 22.19 in |
| Compressed Length | 14.07 in |
| Top Mount | Tie Rod Clamp |
| Bottom Mount | Eyelet |
| Tie Rod Fitment | 1-1/2in |
| What’s Included | Stabilizer with application-specific mounting hardware |
| Warranty | FOX® Limited Lifetime Warranty |
This ATS stabilizer is sized for a 1-1/2 inch tie rod clamp on 2007-2018 Jeep Wrangler JK models and includes a 24-click external adjuster for on-vehicle tuning. Confirm your tie rod diameter before purchase – this part number does not fit 1-5/8in aftermarket tie rods (FOX® part number 983-02-146) or stock/1-3/8in tie rods (FOX® part number 983-02-145).
