Description
The FOX® 985-02-006 is a 2.0 Performance Series 5.425in IFP Coilover Shock (Aluminum), a front-position, bolt-on unit for 0-2in of lift, fitting 2009-2013 Ford F-150 4WD models.
IMPORTANT: This listing is for the front, 4WD-specific application only — one (1) shock, sold individually. Rear shocks and 2WD-specific applications are sold separately. For the 2WD version of this same generation, see FOX® part number 983-02-052.
This bolt-on coilover shock upgrades the stock front suspension with no vehicle modifications required, using a precision, impact-extruded and CNC-machined 6061-T6 aluminum body that increases cooling capacity versus the factory twin-tube design while resisting corrosion over time. The vehicle-specific upper mount uses a composite bushing to isolate noise and vibration from the cabin.
A locking, spring preload ring lets you fine-tune ride height and preload while retaining a racing-grade coil spring matched to the application’s ideal spring rate. This allows the truck to be leveled front-to-rear without altering the stock ride characteristics.
Inside, an Internal Floating Piston (IFP) mono-tube reservoir design keeps the shock oil fully separated from the nitrogen-charged gas chamber. Separating the two eliminates oil aeration under hard use, so the factory-tuned, application-specific valving keeps performing consistently whether on-road or off.
The body is built from impact-extruded, CNC-machined 6061-T6 aluminum with a clear-anodized finish for corrosion resistance, paired with a 5/8in hard chrome-plated, heat-treated alloy steel shaft. A race-developed high-flow piston and a redundant sealing pack (main, wiper, and scraper seals) keep the unit performing over the long haul, backed by large-diameter, heavy-duty spherical bearings at the mounts. Every FOX® shock is fully serviceable and re-valveable, and this unit carries FOX®’s Limited Lifetime Warranty.
- Fits 4WD Ford F-150: FX4 (2009-2013), King Ranch (2009-2013), Lariat (2009-2013), Lariat Limited (2011), Limited (2013), Platinum (2009-2013), STX (2009-2013), XL (2009-2013), XLT (2009-2013) — Front position, 0-2in lift
- 2.0in impact-extruded, CNC-machined 6061-T6 clear-anodized aluminum body
- Internal Floating Piston (IFP) mono-tube reservoir separates shock oil from nitrogen-charged gas
- Locking spring preload ring for adjustable ride height and preload
- 5/8in hard chrome-plated, heat-treated alloy steel shaft
- Race-developed high-flow piston with application-specific valving
- Redundant sealing pack: main seal, wiper seal, scraper seal
- Large-diameter, heavy-duty spherical bearings
- Limited Lifetime Warranty
- Sold individually
| Part Number | 985-02-006 |
| Series | Performance |
| Travel | 5.39in |
| Body | 2.0in impact extruded and CNC machined 6061-T6 clear-anodized aluminum one-piece body |
| Body Plating | Clear-anodized for a durable finish |
| Components | Black-anodized, CNC-machined 6061-T6 billet aluminum |
| Shaft | 5/8in hard chrome plated heat-treated alloy steel |
| Piston | Race-developed high-flow piston design |
| Valving | Application-specific valving to maximize performance |
| Seals | Redundant sealing pack system: main seal, wiper seal, scraper seal |
| Bearings | Large diameter, heavy-duty spherical |
| Extended Length | 21.99in |
| Compressed Length | 16.6in |
| Top Mount | TM |
| Bottom Mount | Eyelet |
| Warranty | Limited Lifetime |
| What’s Included | One (1) FOX® 2.0 Performance Series Coilover IFP Shock, front, sold individually |
This shock is built specifically for the front, 4WD application of the 2009-2013 Ford F-150, covering FX4, King Ranch, Lariat, Lariat Limited, Limited, Platinum, STX, XL, and XLT trims at 0-2in of lift. This is the 4WD-specific coilover — for 2WD trucks of the same generation, order FOX® part number 983-02-052 instead.
