Description
987-24-033: FOX® 2.5 Performance Series HTO Front Shock, 4 inch lift, for 2020-2026 Chevrolet Silverado 2500 HD, Chevrolet Silverado 3500 HD, GMC Sierra 2500 HD, and GMC Sierra 3500 HD.
IMPORTANT: Not for use with lift kits that change OE mounts. This SKU is built for the redesigned 2020+ Silverado/Sierra 2500 HD and 3500 HD platform only – it is not compatible with the 2011-2019 generation. For the equivalent 4 inch front lift application on the 2011-2019 platform, see part number 987-24-032. For other lift heights on this same 2020+ platform, see part number 987-24-008 (0-1 inch) or 987-24-010 (1.5-2.5 inch). Sold individually, one shock per shock absorber position.
The FOX® 2.5 Performance Series HTO shock is a bolt-on shock loaded with position-sensitive technology, vehicle-specific valving, and larger pistons to improve on and off-road performance. A type II anodized aluminum body efficiently dissipates heat and prevents corrosion. The 2.5-inch shock body features an internal floating piston (IFP) to separate the shock oil from the high-pressure nitrogen, optimizing damping.
Hydraulic Top Out (HTO) technology offers usable position-sensitive rebound damping control on and off the pavement. HTO reduces harsh top-outs and increases comfort by forcing shock oil through a secondary shim stack to slow down shock shaft speed. HTO is particularly beneficial after installing heavier, aggressive tires and on applications lifted higher than OEM specification.
This bolt-on FOX® 2.5 Performance Series HTO shock increases damping capacity and ride comfort with position-sensitive rebound control, and is backed by FOX®’s Limited Lifetime Warranty.
- Fits 2020-2026 Chevrolet Silverado 2500 HD, Chevrolet Silverado 3500 HD, GMC Sierra 2500 HD, and GMC Sierra 3500 HD with 4 inches of front lift; not for use with lift kits that change OE mounts
- 2.5″ impact-extruded 6061-T6 aluminum shock body with type II clear-anodized plating for heat dissipation and corrosion resistance
- High-flow, velocity-sensitive damping with vehicle-specific valving
- 5/8″ hard chrome shaft
- Internal floating piston (IFP) separates shock oil from high-pressure nitrogen
- Hydraulic Top Out (HTO) piston reduces harsh top-outs and improves comfort at speed
- Bar pin top mount, clevis bottom mount
- Backed by FOX®’s Limited Lifetime Warranty
- Sold individually
| Part Number | 987-24-033 |
| Brand | FOX® |
| Series | 2.5 Performance Series |
| Position | Front |
| Lift Height | 4 inches |
| Travel | 6.49 inches |
| Extended Length | 21.25 inches |
| Compressed Length | 14.77 inches |
| Top Mount | Bar Pin |
| Bottom Mount | Clevis |
| Shaft Diameter | 5/8″ hard chrome |
| Piston Type | Internal Floating Piston (IFP) with Hydraulic Top Out (HTO) |
| Fitment Restriction | Not for use with lift kits that change OE mounts |
| Warranty | FOX® Limited Lifetime Warranty |
| What’s Included | (1) FOX® 2.5 Performance Series HTO Front Shock, sold individually |
This FOX® 2.5 Performance Series HTO shock is engineered specifically for the Front position on 2020-2026 Chevrolet Silverado 2500 HD, Chevrolet Silverado 3500 HD, GMC Sierra 2500 HD, and GMC Sierra 3500 HD trucks running 4 inches of front lift. This SKU fits the 2020+ generation only – for the 2011-2019 platform at the same 4 inch front lift, order part number 987-24-032 instead.
