Description
The FOX® 981-30-408-L is a Factory Race Series 3.0 x 14in External Bypass (3-Tube) remote reservoir shock, built for the LEFT side of the vehicle, using externally adjustable position-sensitive damping.
IMPORTANT: This part number, 981-30-408-L, is the LEFT side shock only and is sold individually — it is not a pair. The corresponding RIGHT side shock is a separate part number, 981-30-408-R, and must be ordered separately to complete a front or rear pair. Left and right External Bypass shocks are side-specific due to bypass tube and reservoir orientation and are not interchangeable side to side. Extended length is 37.51in and compressed length is 23.6in — confirm these dimensions match your application before ordering.
External Bypass shocks use tubes mounted alongside the shock body, each corresponding to a specific zone of the shock’s stroke, to give externally adjustable, position-sensitive compression damping. This 3-Tube configuration provides three independently tunable compression zones so the shock’s damping curve can be adjusted to match a given vehicle’s weight, terrain, and speed without opening the shock.
FOX® describes this as a revitalized version of its externally adjustable position-sensitive damping architecture, refined for improved performance, durability, and production consistency compared to earlier External Bypass designs.
The shock uses a wire ring bearing design and is finished in FOX® Grey Cerakote® body plating for corrosion resistance. FOX® Factory Race Series suspension products carry FOX®’s Limited One (1) Year Warranty against defects in materials and workmanship from the date of original retail purchase.
- 3.0in body, 14in travel External Bypass (3-Tube) remote reservoir shock — LEFT side only, universal fit
- 3-Tube externally adjustable position-sensitive compression damping
- Wire ring bearing design
- FOX® Grey Cerakote® body plating
- Eyelet top and bottom mounts
- Extended length 37.51in / Compressed length 23.6in
- FOX® Limited One (1) Year Warranty on suspension products
- Sold individually — LEFT side shock only; RIGHT side is part number 981-30-408-R
| Part Number | 981-30-408-L |
| Series | Factory Race |
| Body Diameter | 3.0in |
| Travel | 14in |
| Configuration | External Bypass (3-Tube), Remote Reservoir |
| Side | Left |
| Body Plating | FOX® Grey Cerakote® |
| Bearings | Wire Ring Bearing Design |
| Seals | 803-04-025 |
| Extended Length | 37.51in |
| Compressed Length | 23.6in |
| Top Mount | Eyelet |
| Bottom Mount | Eyelet |
| What’s Included | 1x Left Side Shock Body |
| Warranty | Limited 1 Year (FOX® Factory Race Series) |
This is a universal-fit 3.0in x 14in External Bypass (3-Tube) remote reservoir shock intended for off-road and race applications where the builder is fitting the shock to a specific chassis rather than a direct-fit factory application. This is the LEFT side shock only, sold individually — the RIGHT side counterpart is part number 981-30-408-R and must be purchased separately. Do not confuse this 3-Tube configuration with the 4-Tube External Bypass variants (e.g. 981-30-418-R/-L), which are a different part number and tuning range.
