Description
The FOX® 985-24-102 2.0 Performance Series Front Reservoir Shock is a bolt-on front shock for 1999-2004 Ford F-250, F-350, F-450, and F-550 Super Duty trucks running a 0-1 inch front lift, delivering 8.62 inches of travel through a 2.0-inch smooth body with an external reservoir.
IMPORTANT: This shock is valved specifically for stock-height to 1-inch-lifted 1999-2004 Super Duty trucks. It includes a billet reservoir mounting clamp and is sold individually. F-250 and F-350 applications are 4WD only; F-450 and F-550 applications are covered across all drive configurations listed by the manufacturer. Confirm your exact truck model and drive configuration before ordering.
The aluminum-bodied FOX® 2.0 Performance Series Reservoir shock delivers race-proven damping performance in an affordable, hassle-free bolt-on package. The impact-extruded 6061-T6 aluminum shock body is clear-anodized for a heat-reducing, corrosion-resistant finish that dissipates heat faster than a conventional steel-body shock.
An external reservoir increases oil and nitrogen capacity for more consistent damping under sustained off-road use, while delivering a distinctive race-inspired look. The black-anodized reservoir mounting clamp and other components are CNC-machined from 6061-T6 billet aluminum.
The race-developed, high-flow damping piston is matched with application-specific valving to deliver predictable ride quality capable of handling rough road conditions. A redundant sealing pack — main seal, wiper seal, and scraper seal — protects against contamination.
The shock uses a 5/8-inch hard chrome-plated shaft with eyelet mounts on both ends. FOX® backs this shock with a Limited Lifetime Warranty.
- Fits 1999-2004 Ford F-250, F-350, F-450, and F-550 Super Duty trucks running a 0-1 inch front lift (F-250/F-350: 4WD; F-450/F-550: all drive configurations)
- 2.0″ impact-extruded 6061-T6 aluminum shock body, clear-anodized
- External reservoir for increased oil and nitrogen capacity
- Includes billet reservoir mounting clamp
- Black-anodized, CNC-machined 6061-T6 billet aluminum reservoir components
- Race-developed high-flow piston with application-specific valving
- 5/8″ hard chrome-plated shaft
- Redundant sealing pack: main seal, wiper seal, scraper seal
- FOX® Limited Lifetime Warranty
- Sold individually
| Part Number | 985-24-102 |
| Position | Front |
| Series | Performance |
| Body Diameter | 2.0″ |
| Travel | 8.62″ |
| Extended Length | 22.52″ |
| Compressed Length | 13.9″ |
| Top Mount | Eyelet |
| Bottom Mount | Eyelet |
| Shaft | 5/8″ hard chrome-plated, heat-treated alloy steel |
| Body Material | Impact-extruded 6061-T6 aluminum, clear-anodized |
| Reservoir Components | Black-anodized, CNC-machined 6061-T6 billet aluminum |
| Seals | Redundant sealing pack (main, wiper, scraper) |
| What’s Included | Shock, external reservoir, billet reservoir mounting clamp |
| Warranty | Limited Lifetime |
| Quantity | Sold individually |
This shock is designed for 1999-2004 Ford F-250, F-350, F-450, and F-550 Super Duty trucks running a 0-1 inch front lift as detailed above. F-250 and F-350 applications require 4WD; F-450 and F-550 applications are covered across the drive configurations listed by the manufacturer. Confirm your exact model and drive configuration before ordering.
