Description
FOX® part number 985-02-133 is a Performance Series 2.0 Coil-Over IFP front shock delivering 0-3in of lift, engineered specifically for U.S.-spec 2019-2023 Ford Ranger models.
IMPORTANT: This shock is built for U.S.-market 2019-2023 Ford Ranger models only and does not fit Rest-of-World (ROW) Ranger variants, which use FOX® part number 985-02-148 (2-3in lift, ROW only). It also does not fit 2024 and newer Ford Ranger models, which are built on the next-generation platform and require FOX® 2.5 Performance Series shocks (part number 987-02-006 front). Sold individually – one shock is needed per front corner.
This bolt-on, Performance Series Coil-Over IFP shock is loaded with advanced technology. The precision, metal impact-extruded aluminum body increases cooling capacity and is rust resistant. The vehicle-specific upper mount includes a composite bushing that isolates noise and vibration.
Locking, spring preload rings allow easy ride height and preload adjustment while retaining a top-quality racing coil, selected to deliver the optimal spring rate. Performance Series Coil-Over IFP shocks bolt on with no modifications and are designed to level the truck front-to-rear. Applications are available for stock and lifted trucks that re-use the stock shock.
Inside, an Internal Floating Piston (IFP) mono-tube design separates the shock oil from the high-pressure, nitrogen-charged gas chamber, eliminating oil aeration and allowing maximum performance from the factory-tuned, precision valving. The 2.0″ body is impact extruded and CNC machined from 6061-T6 aluminum with a clear-anodized finish, paired with a 5/8″ hard chrome-plated, heat-treated alloy steel shaft and large-diameter, heavy-duty spherical bearings. FOX® backs this shock with a Limited Lifetime Warranty.
- Fitment: Front coil-over shock for 2019-2023 Ford Ranger (U.S. models only), 0-3in lift, direct bolt-on with no modifications
- Composite-bushed, vehicle-specific upper mount isolates noise and vibration
- Locking spring preload rings for easy ride height and preload adjustment
- 2.0″ impact-extruded, CNC-machined 6061-T6 clear-anodized aluminum body resists corrosion
- 5/8″ hard chrome-plated, heat-treated alloy steel shaft
- Internal Floating Piston (IFP) mono-tube design eliminates oil aeration for consistent damping
- Redundant sealing pack: main seal, wiper seal, and scraper seal
- Large-diameter, heavy-duty spherical bearings
- FOX® Limited Lifetime Warranty
- Sold individually
| Part Number | 985-02-133 |
| Series | Performance |
| Position | Front |
| Travel | 4.39 in |
| Extended Length | 19.39 in |
| Compressed Length | 15 in |
| Body | 2.0″ impact-extruded, CNC-machined 6061-T6 clear-anodized aluminum |
| Components | Black-anodized, CNC-machined 6061-T6 billet aluminum |
| Shaft | 5/8″ hard chrome-plated, heat-treated alloy steel |
| Piston | Race-developed high-flow piston design |
| Valving | Application-specific valving |
| Seals | Redundant sealing pack – main seal, wiper seal, scraper seal |
| Bearings | Large diameter, heavy-duty spherical |
| Top Mount | TM |
| Bottom Mount | Bar Pin |
| Lift Height | 0-3 in |
| Warranty | FOX® Limited Lifetime Warranty |
| What’s Included | 1x FOX® 985-02-133 Front Coil-Over IFP Shock |
This shock is application-specific to U.S.-market 2019-2023 Ford Ranger trucks in the front position, delivering 0-3in of lift across all trims, drive types, and cab configurations. Note: This part fits U.S.-spec, previous-generation (2019-2023) Ranger models only. It is not interchangeable with FOX® 985-02-148 (ROW-market Ranger, 2-3in lift) or with FOX® 987-02-006, the front shock used on the next-generation 2024 and newer Ford Ranger.
