Description
The FOX® 985-24-104 2.0 Performance Series shock is a 12.12-inch travel, smooth-body rear shock with an external bypass piggyback reservoir, fitting Ford F-250, F-350, F-450, and F-550 Super Duty trucks across model years 1999-2016 at ride heights that vary by model and year.
IMPORTANT: Lift height compatibility is not uniform across this shock’s full application range. F-250 Super Duty (1999-2016) and most F-350 Super Duty years fit at 0-1in of lift; F-350 Super Duty model years 2009, 2014, and 2016 instead require 1-2in of lift. F-450 Super Duty fitment alternates by year between 0-1in of lift (2009, 2011, 2013, 2015) and 4.5-5.5in of lift (2005-2008, 2010, 2012, 2014, 2016). F-550 Super Duty (2005-2016) fits at 4.5-5.5in of lift across all covered years. Confirm your exact model year and current ride height against the fitment table below before ordering. Trucks running 4-6in of rear lift should see FOX® part number 985-24-106 instead. FOX® direct-replacement smooth body shocks should always be installed as a pair for consistent handling.
The aluminum-bodied Performance Series 2.0 Reservoir smooth body shock delivers FOX’s race-developed damping performance in an affordable, hassle-free bolt-on package. Its heat-reducing design uses a metal-impacted, clear-anodized aluminum shock body that dissipates heat faster than a conventional steel-body shock.
The external reservoir adds oil and nitrogen capacity while giving the shock a distinct race look. The included black-anodized reservoir mounting clamp and other components are CNC-machined from 6061-T6 aluminum. A race-developed high-flow damping piston matched with application-specific valving delivers predictable ride quality capable of handling rough road conditions.
The shock body is 2.0″ impact-extruded 6061-T6 aluminum that resists rust over time, with a clear-anodized finish for durability. The shaft is 5/8″ hard chrome-plated, heat-treated alloy steel, sealed with a redundant sealing pack system (main seal, wiper seal, scraper seal). FOX® backs this shock with a Limited Lifetime Warranty.
- Rear shock, 12.12in travel, fits Ford F-250/F-350/F-450/F-550 Super Duty 1999-2016 — lift height varies by model and year, see fitment table
- 2.0″ impact-extruded 6061-T6 clear-anodized aluminum body resists rust
- External piggyback reservoir with included billet reservoir clamp increases oil and nitrogen capacity
- Race-developed high-flow piston with application-specific valving
- 5/8″ hard chrome-plated, heat-treated alloy steel shaft
- Redundant sealing pack system: main seal, wiper seal, scraper seal
- Eyelet top mount, eyelet bottom mount
- Limited Lifetime Warranty
- Sold individually
| Part Number | 985-24-104 |
| Series | Performance |
| Position | Rear |
| Travel | 12.12 in |
| Body | 2.0″ impact extruded 6061-T6 aluminum |
| Body Plating | Clear-anodized |
| Components | Black-anodized, CNC-machined 6061-T6 billet aluminum |
| Shaft | 5/8″ hard chrome plated, heat-treated alloy steel |
| Piston | Race-developed high-flow piston design |
| Valving | Application-specific valving |
| Seals | Redundant sealing pack: main seal, wiper seal, scraper seal |
| Extended Length | 30.02 in |
| Compressed Length | 17.9 in |
| Top Mount | Eyelet |
| Bottom Mount | Eyelet |
| Warranty | Limited Lifetime |
| What’s Included | Rear shock, billet reservoir clamp, mounting hardware |
This rear shock covers Ford F-250, F-350, F-450, and F-550 Super Duty trucks from 1999-2016. Lift height compatibility differs by model and specific year — F-250 and most F-350 years run at 0-1in of lift, F-350 model years 2009/2014/2016 run at 1-2in, F-450 alternates by year between 0-1in and 4.5-5.5in, and F-550 runs at 4.5-5.5in across all years. Verify your exact model year against the fitment table above before ordering — trucks with 4-6in of rear lift need FOX® part number 985-24-106 instead.
